Portable Laser Welders Handheld 1000W 1500W Air Cooled
1. Model no.: ZE-LW
2. Laser type: fiber laser
3. Laser power: 1KW, 1.5KW
4. Cooling: water cooled
5. Payment: T/T(optional)
6. Application: gold and silver ring, all Metals, stainless steel, etc.
Product Description
Portable Laser Welders Handheld 1000W 1500W Air Cooled
Features:
1.Handheld fibre laser welder is Portable and flexible, easy and simple operation, meet the welding of multiple angles and positions;
2.Equipped with 5m/10m imported optical fiber, flexible and convenient for outdoor welding;
3.Infrared positioning is used to verify the welding head position and verify the position during welding. The welding position is more accurate to ensure a more beautiful weld;
4.Not easy to deform, easy to polish and polish. Solved the problems of welding penetration, welding nugget, welding quality and other problems that occurred when using argon arc welding;
5.The laser welding depth is large and the welding seam is firm. It is suitable for spot welding of various complicated welding seams and various devices.
|
Name
|
Handheld Fiber Laser Welding Machine
|
|
Laser Power
|
1000W/ 1500W
|
|
Laser Wavelength
|
1070NM
|
|
Fiber Length
|
Standard 8-10M supports up to 15M
|
|
Way of Working
|
Continuous/ Modulation
|
|
Speed Range of Welding Machine
|
0-120mm/s
|
|
Cooling Water Machine
|
Industrial Constant Temperature Water Tank
|
|
Working Environment Temperature Range
|
15~35°c
|
|
Recommended Welding Thickness
|
0.5~5mm
|
|
Welding gap requirments
|
≤0.5mm
|
|
Operating Voltage
|
AV 220V
|
Handheld fibre laser welder Machine Details:
Application Samples:
1. Handheld laser welder is suitable for welding of gold, silver, titanium, nickel, tin, copper,
2. Aluminum and other metal and its alloy material, can achieve the same precision welding between metal and dissimilar metals,
3. Aerospace equipment, shipbuilding, instrumentation, mechanical and electrical products, automotive and other industries.
Packing And Shipping:
1. Inner package: waterproof plastic transparent film
2. Middle package: white foam, to protect the machine from shaking
3. Outside package: wooded case free of fumigation
4. According to different customer needs,we could send the cargo by air, sea,and railways
5. The delivery lead time would be 3-5 days
FAQs:
1. How much thickness can you weld?
This depends on the welding material and welding requirements, our penetration depth can reach 4.5.
In this case, the maximum thickness can be welded up to 7-8, and the specific welding must be done at the factory for proofing.
2. What is the maximum weld width?
2mm or less, our wire feeder supports 2mm welding wire.
3. How many watts do your laser welding machines?
1000w,1500w,2000w with Raycus, Jpt and Max
4. What materials can be welded?
Stainless steel, carbon steel, galvanized sheet, aluminum sheet.
5. Can you weld the effect of fish scales?
Yes. When you buy the machine, our engineer will teach you how to weld the fish scale effect.
