Portable UV Laser Engraver 355nm Wavelength

1. Model no.: ZE-UV1
2. Laser type: 355nm uv laser
3. Laser power: 3watt, 5watt
4. Cooling: air cooled
5. Payment: T/T(optional)
6. Application: gold and silver ring, all non-Metals, stainless steel, etc.

Machine Details

Portable UV laser engraver 355nm wavelength features:

1. Portable UV Laser Engraver is smaller focused spot size, ultra-fine marking, and the minimum character can up to 0.2mm.
2. 355nm outgoing wavelength makes it small heat-affected area without thermal effects and burning problem.
3. Motorized up down table, auto focusing, and rotating functions are optional.
4. High speed and high precision.
5. Stable working performance without consumable material, small size and easy operation.
6. It can greatly reduce the mechanical deformation of material,
and reduce heat effect on work piece.
7. The 355nm wavelength UV laser has extemely small size spot, more precision.

Machine detail pictures:

UV Laser Engraver

UV Laser Engraver

Machine Details:

1. 355nm uv laser source
2. High speed galvo laser head
3. High light transmission lens
4. More stable water chiller

UV Laser Engraver


Technical parameters:

Model: ZE-UV1
LaZer type: uv laser
Wavelength: 355nm
Laser power: 3W, 5W
Average output power: >3W@50kHz>5W@50kHz
Software: EZCAD/Touch screen operation
Single pulse energy: >75μJ@40kHz>125μJ@40kHz
Repetition frequency: 20kHz~200kHz
Pulse width: <22ns@40kHz<18ns@50kHz
Maximum speed: 7000mm/s
resolution: 0.01mm
Re-positioning precision: 0.03mm
Marking range: 110*110mm
Minimum line width: 0.01mm
Minimum height of characters: 0.2mm
Cooling way: Water cooling
Laser power supply: 0.8KW/AC220V/50Hz
Environmental requirements: 10 ~ 35 ° C, 90% or humidity


Application samples:

1. Steel and Stainless steel
2. Bare and Cast Aluminum
3. Gold and Silver
4. Copper, Glass cup
5. Titanium,Wood
6. Plastics, all non-metals

UV Laser Engraver

Package And Shipping:

1. Inner package: waterproof plastic transparent film
2. Middle package: white foam, to protect the machine from shaking
3. Outside package: wooded case free of fumigation
4. According to different customer needs,we could send the cargo by air, sea,and railways
5. The delivery lead time would be 3-5 days

UV Laser Engraver

UV Laser Engraver


Q1. How to get the most suitable machine and best price?
First, you need to tell us what material or product you want to mark.
Then we will recommend you the best model.

Q2. Quality Control?
The whole production procedure will be under regular inspection and strict quality control.
And all machine approval with CE & FDA

Q3: How is the shipping method?
As per your actual address, we can effect shipment by sea, by air, by truck or railway.
The customers can choose the most suitable shipping way for them.

Q4: This model is not suitable for me, do you have more models available?
Yes, it will need you to send us the samples to test for you.
We can use the following machine to test for you, and choose the best effect
portable fiber laser marking machine,
co2 laser marking machine,
enclosed fiber laser marking machine,
3D fiber laser marking macine,
UV laser marking machine and so on.
